Mineral Exploration Core Drilling Diamond Core Drill Bits for Hardness Rock formations

1 - 5 pcs
MOQ
Negotiate
السعر
Mineral Exploration Core Drilling Diamond Core Drill Bits for Hardness Rock formations
ميزات صالة عرض منتوج وصف طلب عرض أسعار
ميزات
مواصفات
Core Bits: diamond core drill rigs
Drills: Wireline Core Drilling
Drill Bits: milwaukee diamond core drill bits
Item: walk behind saw
Diamond bits: dremel diamond bits
Bit: diamond bit drill
Diamond: diamond tip drill bit
Drilling: Exploration Core Drilling
Item No: Diamond Core Drill Bits
Core Drilling: Diamond-core drilling
Origin: China Core Drilling Diamond Core Drill Bits
Sales: Shop Diamond Core Drill Bits For Sale
Series: Wireline Diamond Core Bits
Model: Impregnated Diamond Core Bits
Mining: Australia Mining
Exploration: Australia Exploration
Model No: Mining Exploration Core Drilling
Usage: Africa Mining
Applications: Copper Mining Drilling
تسليط الضوء:

Diamond Core Drilling Bits,Diamond Core Drill Bits For Rock

,

Diamond Core Drill Bits For Rock

معلومات اساسية
مكان المنشأ: USA
اسم العلامة التجارية: ROSCHEN
إصدار الشهادات: ISO
رقم الموديل: BQ NQ HQ PQ
شروط الدفع والشحن
تفاصيل التغليف: Carton box
القدرة على العرض: 10000 pcs
منتوج وصف

Mineral Exploration Core Drilling Diamond Core Drill Bits Coring Samples for Hardness Rock formations




Mineral Exploration Core Drilling



BEING ABLE TO DRILL STRAIGHTER AND FASTER WITH DIASET BITS WILL SAVE YOUR CUSTOMERS TIME AND MONEY.


Diamond core drilling, or more commonly called diamond drilling, has always been a vital part of subterranean exploration. Enormous financial commitments are made based on the results of hundreds of thousands of meters of core samples worldwide. The mineral exploration driller must accurately recover complete core samples so geologists and engineers can assess the structure and value of mineral exploration targets. To do this competitively, high quality diamond drilling tools are required to ensure high penetration rates, straight drill holes and complete core recovery.


We have been manufacturing consumable drilling tools for the mineral exploration industry for the past 40 years. Three decades of manufacturing expertise combined with real-world core drilling experience has resulted in the highest quality drilling tools designed to cut faster, straighter and use less energy.


Below you will find a selection of precision manufactured diamond drilling tools designed to generate the most core recovery and last longer than any other tools on the market.


Specificiations:

STANDARD SET DIMENSIONS FOR DIAMOND CORE BITS AND REAMING SHELLS
Core Barrel Designation Core Bit Core Bit Reaming Shell
Outside Set Diameter Inside Set Diameter Set Diameter
Maximum Minimum Maximum Minimum Maximum Minimum
Inches mm Inches mm Inches mm Inches mm Inches mm Inches mm
EWT(EXT) 1.475 37.46 1.465 37.21 0.91 23.11 0.9 22.86 1.49 37.85 1.48 37.59
IEWS 1.475 37.46 1.465 37.21 1 25.4 0.99 25.15 1.49 37.85 1.48 37.59
EWG 1.475 37.46 1.465 37.21 0.85 21.59 0.84 21.34 1.49 37.85 1.48 37.592
AQ 1.88 47.75 1.87 47.5 1.067 27.1 1.057 26.85 1.895 48.13 1.885 47.88
AQIK 1.88 47.75 1.87 47.5 1.206 30.63 1.196 30.38 1.895 48.13 1.885 47.88
ATW(ADB-GM) 1.88 47.75 1.87 47.5 1.198 30.43 1.188 30.18 1.895 48.13 1.885 47.88
AWT(AXT) 1.88 47.75 1.87 47.5 1.286 32.66 1.276 32.41 1.895 48.13 1.885 47.88
ATK34(AW34) 1.88 47.75 1.87 47.5 1.325 33.66 1.315 33.4 1.895 48.13 1.885 47.88
AXC(AWC3) 1.895 48.13 1.855 47.88 1.067 27.1 1.057 26.85 1.895 48.13 1.885 47.88
JTK48/LTK48 1.88 47.75 1.87 47.5 1.394 35.41 1.384 35.15 1.895 48.13 1.885 47.88
BQ 2.35 59.69 2.34 59.44 1.438 36.53 1.428 36.27 2.365 60.07 2.355 59.82
BQ3 2.35 59.69 2.34 59.44 1.325 33.65 1.315 33.4 2.365 60.07 2.355 59.82
BQTK 2.35 59.69 2.34 59.44 1.606 40.79 1.596 40.54 2.365 60.07 2.355 59.82
BXB(BWC3) 2.365 60.07 2.355 59.82 1.438 36.53 1.428 36.27 2.365 60.07 2.355 59.82
BWG(BX) 2.35 59.69 2.34 59.44 1.659 42.14 1.649 41.88 2.365 60.07 2.355 59.82
NQ 2.97 75,44 2.96 75.18 1.88 47.75 1.87 47.5 2.985 75.82 2.975 75.57
NQ2 2.97 75.44 2.96 75.18 2 50.8 1.99 50.65 2.985 75.82 2.975 75.57
NQ3/NQTT 2.97 75.44 2.96 75.18 1.78 45.21 1.77 44.96 2.985 75.82 2.975 75.57
NWG(NX) 2.97 75.44 2.96 75.18 2.16 54.86 2.15 54.61 2.985 75.82 2.975 75.57
NMLC 2.97 75.44 2.96 75.18 2.052 52.12 2.042 51.87 2.985 75.82 2.975 75.57
HQ 3.77 95.76 3.755 95.38 2.505 63.63 2.495 63.38 3.79 96.27 3.775 95.89
HQ3/HQTT 3.77 95.76 3.755 95.38 2.411 61.24 2.401 60.99 3.79 96.27 3.775 95.89
PQ 4.815 122.3 4.795 121.8 3.35 85.09 3.34 84.84 4.835 120.81 4.82 122.43
PQ3 4.815 122.3 4.795 121.8 3.275 83.19 3.265 82.93 4.835 122.81 4.82 122.43
TT46/LTK46 1.816 46.12 1.806 45.87 1.394 35.41 1.384 35.15 1.828 46.42 1.818 46.17
T2-46 1.816 46.12 1.806 45.87 1.253 31.82 1.243 31.56 1.828 46.42 1.818 46.17
T2-56 2.21 56.12 2.2 55.87 1.647 41.82 1.637 41.56 2.222 56.42 2.212 56.17
T2-66 2.603 66.12 2.593 65.87 2.04 51.82 2.03 51.56 2.615 66.42 2.605 66.17
T2-76 2.997 76.12 2.987 75.87 2.434 61.82 2.424 61.56 3.009 76.42 2.999 76.17
T2-86 3.391 86.12 3.381 85.87 2.828 71.82 2.818 71.56 3.403 86.42 3.393 86.17
T2-101 3.982 101.14 3.97 100.84 3.3 83.82 3.29 83.56 3.994 101.44 3.984 101.19
T6-86 3.391 86.12 3.381 85.87 2.643 67.13 2.633 66.88 3.406 86.51 3.394 86.21
T6-H 3.897 98.98 3.882 98.6 3.115 79.13 3.105 76.88 3.912 99.36 3.902 99.11
T6-101 3.982 101.14 3.97 100.84 3.115 79.13 3.105 78.88 3.996 101.51 3.984 101.21
T6-116 4.575 116.18 4.56 115.8 3.667 93.13 3.657 92.88 4.59 116.59 4.575 116.21
T6-131 5.165 131.18 5.15 130.8 4.257 108.13 4.247 107.88 5.18 131.59 5.165 131.21
T6-146 5.755 146.18 5.74 145.8 4.847 123.13 4.837 122.88 5.772 146.61 5.757 146






FAQ



Q: Are you a manufacturer or trading company?
A: We are a specialized manufacturer.


Q: What are your main products, and used for?
A: Our products include core bit, PDC bit, reaming shell, core barrel, casing, drill rod, SPT equipment, Shelby sampler, drill rig and other drilling parts.
They are used for mineral exploration, geological drilling, geotechnical engineering and soil sampling.


Q: How about the delivery terms?
1. Payment: T/T, L/C, Western Union, Paypal, 30% deposit in advance and rest before delivery.
2. Min. order quantity: 1 piece.
3. Transportation: By DHL/TNT/Fedex express, air, sea, train.


Q: How about discount?
A: Price is based on products and order quantity.


Q: Do you accept sample order?
A: Yes sure, please contact us for details.


Q: How about your after-sales service?
A: As a manufacturer, we offer promt technology support for all problems and questions. Besides, we accept goods return or replace for quality problem.


Q: How does your company control the quality?
A: Quality first. In order to guarantee high quality for our products, Roschen always makes a serious inspection for all products and raw materials in strict procedure. We have obtained certificate of ISO9001:2000 in 2004.
